32
d3.33
25020C10
Analog_MaxT_Fa
ctor
Indicates the max torque factor on analog
signal control
8192
N/A
d3.34
25080110
Gear_Factor
Indicates the numerator to set electronic
gears when the operation mode is -4
1000
-32767~3
2767
d3.35
25080210
Gear_Divider
Indicates the denominator to set electronic
gears when the operation mode is -4
1000
1~32767
d3.36
25080308
PD_CW
0: Double pulse (CW/CCW) mode
1. Pulse Direction (P/D) mode
Note: To change this parameter, you need
to save it with the address ―d5.00‖, and
restarts it later.
1
N/A
d3.37
25080610
PD_Filter
To flat the input pulse.
Filter frequency: f=1000/(2π* PD_Filter)
Time constant: T = PD_Filter/1000
Unit: S
Note: If you adjust this filter parameter
during the operation, some pulses may be
lost.
3
1~32767
d3.38
25080810
Frequency_Chec
k
Indicates the limitation on pulse input
frequency (k Hz)
600
0~600
d3.39
25080910
PD_ReachT
Indicates the position reached time window
in the pulse mode
Unit: mS
10
0~32767
d3.40
2FF10108
Panel32_N
To select which parameter will be set.
0. Din_Pos0
1. Din_Pos1
2. Din_Pos2
3. Din_Pos3
4. Din_Pos4
5. Din_Pos5
6. Din_Pos6
7. Din_Pos7
0
N/A
d3.41
2FF10210
Panel32_H
The high part of Din_Pos.
Din_Pos=Panel32_H*10000+Panel32_L
0
-32767~3
2767
d3.42
2FF10310
Panel32_L
The low part of Din_Pos.
Din_Pos =Panel32_H*10000+Panel32_L
0
-32767~3
2767
d3.43
20200F10
Din_Control_Wor
d
Input Enable signal controls the control
word.
0
N/A
d3.44
20201810
Din_Speed4_RP
M
Multi-speed control: 4 [rpm]
0
N/A
d3.45
20201910
Din_Speed5_RP
M
Multi-speed control: 5 [rpm]
0
N/A
d3.46
20201A10
Din_Speed6_RP
M
Multi-speed control: 6 [rpm]
0
N/A
d3.47
20201B10
Din_Speed7_RP
M
Multi-speed control: 7 [rpm]
0
N/A
