Fuel system
Injection pump tting in the crankcase
Fit pad 2 into the tappet so that recess B points downwards as shown
inthegure. (Forpadspacer,seeg.165)
Fit the injection pump into the crankcase complete with gasket po-
sitioning ow control 1 in the fork of lever 5 which should be in the
maximumowposition.
Caution – Warning
When removing the injection pump from its housing make sure
that spacer 2 is not dropped into the oil sump; injection pump
operation will be hampered if the spacer is not installed.
Injection pump
ThisisofthesimpliedQLCtype;itishousedinthecrankcaseandis
controlled by the camshaft via tappets.
Solenoid valve
Dimensions (mm)
Characteristics:
12 V 0.9 A.
