Korg microKONTROL - NRPN (NRPN Message)

Operation–Message mode
49
5
Press the OCTAVE SHIFT/CURSOR [ ® ] key to proceed to “Dt_M:”
(specify the Data Entry MSB that follows CC#6).
6
Use the [VALUE] dial or the pads to input the Data Entry MSB value.
The range is
0–127 .
7
Press the OCTAVE SHIFT/CURSOR [ ® ] to proceed to “Dt_L:” (specify
the Data Entry LSB that follows CC#38).
8
Use the [VALUE] dial or the pads to input the Data Entry LSB value.
The range is
0–127 .
9
Press the OCTAVE SHIFT/CURSOR [ ® ] key to proceed to “MIDI
Channel” (specify the MIDI channel).
10
Use the [VALUE] dial or the pads to select the MIDI channel on which
the specified RPN message will be transmitted. The range is
1–16 (ch) .
11
Press the [ENTER] key to transmit the message.
When transmission is completed, the main display will indicate
“Trnsmit!” and you will return to Play mode.
If you press the [EXIT] key, the scene number will be displayed.
The next time that you use this function, the previously-specified
message will be displayed. The microKONTROL will remember this
message until you turn off the power.
[14] NRPN (NRPN message)
This lets you transmit any desired NRPN (Non Registered Parameter
Number)
message.
NRPN messages can be used to make settings that are specific to individual
instrument manufacturers or devices.
The parameter number is specified by the combination of two controllers,
CC#99 (MSB) and CC#98 (LSB). After the parameter number is specified, its
value is specified by another pair of controllers: CC#6 (MSB) and CC#38
(LSB).
1
Hold down [MESSAGE] and press pad [14].
The [MESSAGE] key and pad [14] will light, and you will enter the
NRPN (NRPN message) page. The main display will indicate “MSB”
(specify the MSB). For more details, refer to “[13] RPN (RPN message)”
(
☞ p.48).
(Green)(Green)
(Green)(Green)
(Green)(Green)
Message mode
 ',   !"
