Korg microKONTROL - Main Specifications

Appendices–Main specifications
64
Main specifications
■ Controllers
• Keyboard: 37-note velocity-sensitive mini-keyboard
• Rotary encoders
× 8
• Sliders
× 8
• Pads
× 16: velocity-sensitive
• Joystick: four-way, with switch
•[VALUE] dial
■ Display
• Main display: 8-character (8 × 5 pixel) LCD module with three-color
backlight
• Sub display
× 8: 8-character (8 × 5 pixel) LCD module with three-color
backlight
•Tempo LED
■ Memory
• User memories: 12
• Global memory: 1
■ Connectors
• Pedal jack
• MIDI IN/OUT connectors
• USB connector
• Power supply jack (DC9V)
■ Power supply
• DC9V, AC adapter
• USB bus-powered (when using the USB connector)
• Six AA batteries
■ Current consumption
• When using USB bus power: approximately 350 mA (Max 450 mA)
• When using the AC adapter: approximately 450 mA (Max 500 mA)
• Battery life: approximately 6 hours (when using six alkaline batteries)
■ Dimensions (W x D x H)
• 521 mm × 231 mm × 67 mm (20.51" × 9.09" × 2.64")
■ Weight
• 2.5 kg (5.51 lbs.)
■ Included items
• AC adapter
• USB cable
• CD-ROM (containing microKONTROL Librarian software, scene tem-
plates, drivers)
•Trigger pad name sheet and labels
• Owner’s manual
• MIDI Implementation chart/Name List
• Software license agreement
■ Requirements for connection to a computer
• Macintosh
• Supported OS: Mac OS X 10.2 or later
• Supported computers: Apple Macintosh with USB port capable of
running Mac OS X
•Windows
• Supported OS: Microsoft Windows XP Home Edition/Professional
• Supported computers: a computer with USB port capable of running
Windows XP (USB chipsets manufactured by Intel Corporation are
recommended)
● Options
• Damper pedal DS-1H
• Pedal switch PS-1
Appearance and specifications are subject to change without notice.
(Current as of August 2003)
 )'   !"
