Operation–Message mode
47
[11] PROG (Program Change message)
This lets you transmit a
program change message [Cn, mm]
(n: channel,
mm: program number)
1
Hold down the [MESSAGE] key and press pad [11].
The [MESSAGE] key and pad [11] will light, and you will enter the
PROG (Program Change message) page. The main display will
indicate “Prog” (select the program number).
2
Use the [VALUE] dial or the pads to input the program number you
want to transmit. The range is
0–127
. (
☞
p.4 “About the trigger pad
functions–Input numerical values”)
3
Press the OCTAVE SHIFT/CURSOR [
®
] key to proceed to “MIDI
Channel” (specify the MIDI channel).
4
Use the [VALUE] dial or the pads to select the MIDI channel on which
the program change message will be transmitted. The range is
1–16
(ch)
.
5
Press the [ENTER] key to transmit the message.
When transmission is completed, the main display will indicate
“Trnsmit!” and you will return to Play mode.
If you press the [EXIT] key, the scene number will be displayed.
The next time that you use this function, the previously-specified
message will be displayed. The microKONTROL will remember this
message until you turn off the power.
[12] BEND (Pitch Bend Change message)
This lets you transmit a
pitch bend message [En, bb, mm]
(n: channel, bb:
LSB, mm: MSB). The combination of the two values, MSB and LSB, let you
specify a total of 16,384 different pitch bend values, where 8,192 (LSB=000,
MSB=064) is the center value.
1
Hold down the [MESSAGE] key and press pad [12].
The [MESSAGE] key and pad [12] will light, and you will enter the
BEND (Pitch Bend Change message) page. The main display will
indicate “LSB” (LSB setting).
2
Use the [VALUE] dial or the pads to input the “LSB” value. The range
is
0–127
. (
☞
p.4 “About the trigger pad functions–Input numerical
values”)
3
Press the OCTAVE SHIFT/CURSOR [
®
] key to proceed to “MSB”
(MSB setting).
4
Use the [VALUE] dial or the pads to input the “MSB” value. The range
is
0–127
.
(Green)(Red)
Message mode
'* !"
