Kramer MV-6 - Page 61

MV-6 - Protocol 3000 Commands
57
Command - OVRLBK
Command Type - Multiviewer
Command Name
Permission
Transparency
Set:
OVRLBK
End User
Public
Get
OVRLBK?
End User
Public
Description
Syntax
Set:
Set text overlay background parameters
#OVRLBK␠stage, stage_id,r,g,b,alpha␍
Get:
Get text overlay background parameters
#OVRLBK?␠stage, stage_id ␍
Response
~ nn@OVRLBK␠stage, stage_id,r,g,b,alpha␍␊
Parameters
stage - input/output - set reference to Section 12.4 Stage
stage_id - number of chosen stage (1.. max number of inputs/outputs)
r - red component value (0-255)
g - green component value (0-255)
b - blue component value (0-255)
alpha - alpha value (0-255)
Response Triggers
After execution, response is sent to the com port from which the Set/Get was received
After execution, response is sent to all com ports if OVRLBK was set by any other external control device
(button press, device menu and similar)
Notes
