Safety
21
1)
Before starting the machine,
read and observe the
operating instructions and
safety instructions.
Order No. 939 471-1 (1x)
2)
The PTO speeds must not exceed 1000 rpm!
The operating pressure of the hydraulic
system must not exceed 200 bar!
939 101-4
MAX.
1000/
min
MAX.
200
bar
Order No. 939 101-4 (1x)
3) Order No. 939 576-0 (4x)
(2x) for EC 28 M / 32 M
a) Caution: some machine parts will stay in
operation for an extended period of time
before being switched off completely. Do
not touch any moving parts of the
machine. Wait until they have come to a
complete stop.
b) Move the protective devices into
protective position prior to start-up.
c) When the machine is running, keep your
distance.
3a 3b 3c
4)
While parts are moving, never
reach into areas where there is
a risk of being crushed.
Order No. 942 196-1 (2x)
(EC 28P/32P)
5)
Order No. 939 106-3
(1x)
6)
Danger in the swivel range
(for EC 28 M / EC 32 M only)
939 472-2
Order No. 939 472-2 (2x)
Pos: 13.13 /BA/-- ---Seitenum bruch------ @ 0\m od_119617531 1226_0.doc @ 4165
540 O.K. 540
1000 O.K. 1000
540 1000
540 730
Lebensgefahr!
Danger de mort!
Livsfara!
Danger to life!
Levensgevaarlijk!
¡Peligro de muerte!
939 410 2
STOP
942 197-1
942 196 -1
