4.13 Position of the General Information Labels on the Machine
Pos: 13.15 /BA/Sic herheit/Auf kleber/EasyCut /Hinweisaufkle ber EasyCut 28/3 2 28P/32P 2 8M @ 29\mod_ 12512742954 30_78.doc @ 2 82045
Fig. 4:
1)
942 342-2 (1x) EasyCut 28
942 343-1 (1x) EasyCut 32
942 561-0 (1x) EasyCut 28P
942 562-0 (1x) EasyCut 32 P
2)
942 301-0 (1x)
3)
255 498-1
min. 14 mm
Ø 17,5 mm
80
255 498-1 (1x) with blade
screw connection
3)
255 499-2
255 499-2 (1x) with
blade Quick-Fit Device
4)
139 888-0 139 889-0
80
139-888
139-889
939 567-1 (1x)
5)
939 161-2 (1x)
6)
942 089-2
120
80
942 089-2 (1x)
