Start-up
32
Pos: 17.18 /BA/I nbetriebnahm e/EasyCut/Über prüfung des Erst anbaues Bild EC28/32 @ 1 0\mod_12217 32152364_78.d oc @ 13659 2
6.4 Checking the First fitting
1
2
EC-221-0
Fig. 12:
Pos: 17.19 /BA/I nbetriebnahm e/EasyCut/Über prüfung des Erst anbaues Te xt EC 28/32 28 /32 CV @ 10\m od_122172961 7083_78.doc @ 136342
To do this:
• Raise the mowing unit
Note
Lift the mowing unit parallel to the ground.
Effect: Conserve functionality and increased service life
• Lifting the mowing unit parallel to the ground will help prevent the
machine from running unevenly due to the PTO shaft.
If this is not so:
• Hook the upper suspension arm (1) into another hole on the tractor or on the Weiste
triangle (2) so that the mowing unit is raised as close as possible parallel to the ground.
