Maintenance
65
Pos: 27.29.4 /B A/Sicherheit/Ge fahrenhinweise /Mähwerke/Sc hnell rotierend e Messerteller/M essertro mmeln_1 @ 0\mod _1197017696 736_78.doc @ 1 6001
Danger!
Rapidly rotating cutting discs/blade drums.
Effect: Danger to life or serious injuries.
Switch off the engine and remove the ignition key.
The cutting discs/blade drums continue to run!
Do not leave the driver’s cab until the cutting discs/blade drums have
come to a complete stop.
Pos: 27.29.5 /B A/Wartung/Mäh werke/Schersic herung/Lege nde Mähhol m Aufstellung Eas yCut´s @ 4\mod _1213098609 195_78.doc @ 8 6463
Explanation of abbreviations:
A= Direction of rotation "A" to the middle
B= Direction of rotation "B" in pairs
RZ= Central bearing housing (clockwise threading), without identifying groove.
RE= Eccentric bearing housing (clockwise threading, without identifying groove).
LZ= Central bearing housing (anticlockwise threading), with identifying groove.
LE= Eccentric bearing housing (anticlockwise threading), with identifying groove.
Pos: 27.29.6 /B A/Wartung/Mäh werke/Schersic herung/Besc hreibung Schersich erung @ 3\ mod_1204205 493155_78.doc @ 69964
For protection against overload on the mowing units, the rotary hubs (1) are secured with nuts
(2) and shear pins (3).
If the machine strikes obstacles (for example stones), the 2 shear pins in the rotary hub will be
sheared off. The rotary hub and nut turn upward on the pinion shaft.
The cutting discs or drums which move crop to the left (as seen in the direction of travel)
(LE/LZ) have left-handed threading.
The cutting discs or drums which move crop to the right (in the direction of travel)
(RE/RZ) have right-handed threading.
To distinguish between right-hand (clockwise) threading (RE/RZ) and left-hand (anti-clockwise)
threading (LE/LZ), the nuts (2) and pinion shaft (4) for left-hand threading (LE/LZ) have a
distinctive grove (a, b).
Left-handed (LE/LZ) nuts (2) have distinctive grooves (a) on the bevel.
Left-handed (LE/LZ) pinion shafts (4) have a distinctive groove (b) on the face.
