Special equipment
75
• Install the plates (1,2). Make certain when attaching the plates that the distance from the
rubber pads (7) to the mower drums is at least 3 mm.
Note
Reinstallation is in the reverse order
Before starting up the machine again, make certain to check the cutter blades,
retaining bolts, cutting discs, and drums as well as the linings
• See Maintenance section “Checking the Cutter Blades and Retaining
Bolts”.
• See Maintenance section “Periodical Inspection of Cutting Discs and
Drums."
• See Maintenance section “Replacing the Linings".
