11 FUEL TANK, SEAT, TRIM 62
Warning
Danger of poisoning Fuel is poisonous and a health hazard.
– Fuel must not come into contact with the skin, eyes, or clothing. Do not breathe in the fuel vapors. If contact occurs with
the eyes, rinse with water immediately and contact a physician. Immediately clean contaminated areas on the skin with
soap and water. If fuel is swallowed, contact a physician immediately. Change clothing that is contaminated with fuel.
Store fuel properly in a suitable canister and keep away from children.
Warning
Environmental hazard Improper handling of fuel is a danger to the environment.
– Do not allow fuel to get into the ground water, the ground, or the sewage system.
Preparatory work
– Switch off all power consumers and switch off the engine.
– Remove the seat. ( p. 59)
– Disconnect the battery. ( p. 79)
– Drain the fuel from the fuel tank into a suitable container.
S00063-10
Main work
– Remove screws 1.
S00064-10
– Lift the rear fairing.
– Remove screws 2.
S00065-12
– Remove screw 3 on both sides.
– Swing the rear end upwards and secure it.
S00327-10
– Remove screws 4 and the splash protector.
