11 FUEL TANK, SEAT, TRIM 63
S00113-10
– Remove screws 5.
– Pull out the fuel pump.
S00328-10
– Disconnect both fuel hose connections 6.
– Unplug connector 7. Remove the fuel pump.
202049-10
– Remove hose clamps 8.
– Remove fuel filter.
– Mount the new fuel filter.
Arrow A points away from the fuel pump.
– Mount hose clamps 8.
Hose clamp pliers (60029057000) ( p. 212)
202050-10
– Press locking mechanism 9 on both sides.
– Pull off the fuel pump housing.
202051-10
– Change fuel screen bk.
– Mount the fuel pump housing.
S00328-10
– Connect both fuel hose connections 6.
– Attach connector 7.
