11 FUEL TANK, SEAT, TRIM 67

S00064-10

– Lift the rear fairing.

– Mount and tighten screws 2.

Guideline

Screw, main silencer holder on fuel

tank

M8 25 Nm

(18.4 lbf ft)

S00063-10

– Mount and tighten screws 1.

Guideline

Screw, side cover M6 5 Nm (3.7 lbf ft)

Finishing work

– Disconnect the battery. ( p. 80)

– Mount the seat. ( p. 60)

– Set the clock. ( p. 95)
