Global Functions
MIDIScope
93
After the second selection, the main MIDIScope screen is active.
Except for SysEx, the bottom line will show a complete 1-3 byte
message with timestamping. A SysEx message will always use
both lines and for long messages will just show the Þrst 10 bytes
including the SOX byte.
While in MIDIScope, the left soft button will freeze the display
and the right soft button will unfreeze the display. The Global
button toggles between symbolic/decimal display and all
hexadecimal display. The Exit button will exit the MIDIScope
screen and back up one level to the Message Select screen. When
re-entering MIDIScope, the last signal and message selections
will be the initial defaults.
MIDI messages may come in faster than they can be displayed. If
more than one additional message has been received, only the
most recent message is displayed next.
MIDIScope: Detailed Operation & Screens
To activate MIDIScope, press the Global button from Setup Select
or List Select mode.
The following screen is displayed:
-GLOBAL SELECT-
EDIT UTILITY
Press the right soft button which brings up:
Load Setups |
Select Execute
Press the left soft button until the following screen is displayed:
MIDIScope
Select Execute
then press the right soft button. The following screen is then
displayed (Source will be either Main Out, Main Inp, Aux Out, or
Aux Inp):
Source: Main Inp
Select Execute
Press the left soft button to go through the 4 source choices. Press
the right soft button to go to the next screen:
*NT *CC *SY *SX
Select Execute
