Editing and Creating Setups
Switch Controller Parameters
41
portamento, while the Toggle mode works best for functions like
turning the Arpeggiator on and off.
The LED above each Panel Switch shows that switchÕs state. In
Momentary mode, an LED lights only as long as you are holding
the switch. In Toggle mode, the light stays on until you press the
Panel Switch again. Keep in mind that one Panel Switch can do
something different in each Zone, and since thereÕs only one light
per switch, the light only shows the switchÕs state for Zone 1.
However, when you press the Panel Switch, it executes its
assignments for all Zones that use the switch.
On Destination (On D), Off Destination (Off D)
On Destination and Off Destination determine what message
will be sent when you turn a switch on or off, respectively. The
list of available Destinations on page 48 is almost the same as for
the continuous controllers, and can be accessed the same way.
ItÕs typical to set the same Destination for both, so that you can
turn a Controller on or off. You could also send two different
messages. For example, you could set Switch Type to momentary,
On Destination to a Bank Select Controller (BkSelM or BkSelL)
and Off Destination to Program Change. Then you can use a
switch or a pedal to call up a program on another instrument that
uses Bank Select to access more than 128 programs.
On Destination and Off Destination can also be set to Ònone,Ó so
that pressing on the switch has no effect at all in a Zone.
On Value (On V)
On Value sets the value of the Controller when you turn the
switch on. For some functions the On Value should be 127. For
example, the default On Destination for SP1 is Controller #64 Ñ
Sustain Ñ with an On Value of 127. In other cases, you might
want a different On Value. For instance, you could use a button
or pedal as a ÒsoftÓ switch to lower a soundÕs volume only part-
way. In this case, you might set the On Destination to Volume (07)
and the On Value to 50.
