Global Functions
MIDIScope
95
System messages (Real Time and System Common) have no
channel and will be represented with 3 character mnemonics as
follows:
'MTC' $F1 MIDI TIME CODE
'SPP' $F2 SONG POSITION POINTER
'SSL' $F3 SONG SELECT
'$F4' $F4 UNDEFINED
'$F5' $F5 UNDEFINED
'TUN' $F6 TUNE REQUEST
'EOX' $F7 END OF EXCLUSIVE
'CLK' $F8 TIMING CLOCK
'$F9' $F9 UNDEFINED
'SRT' $FA START
'CON' $FB CONTINUE
'STP' $FC STOP
'$FD' $FD UNDEFINED
'SNS' $FE ACTIVE SENSING
'RES' $FF SYSTEM RESET
System exclusive messages will be displayed as follows:
SOX XX XX XX XX
|XX XX XX XX EOX
where "XX" is always the byte value in hex. Only the Þrst 10
bytes, including SOX, will appear. If the message is shorter than
11 bytes, EOX will appear as the last byte. SysEx messages always
use both display lines.
When the left soft button is pressed, the current display content is
frozen for analysis and additional messages received are skipped.
When the right soft button is pressed, the screen will continue to
be displayed until the next message is received.
Press Exit to leave MIDIScope mode and return to the message
type selection. It will take three Exits to return to Setup Select.
Subsequent selection of MIDIScope will retain the last signal
source and message type selections as defaults. Thus one tap on
Global and 3 taps of the right soft button will return to active
MIDIScope mode. On re-entry, the screen will always start off
unfrozen.
