KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 182 -
E329
E329 Bolt driven out
Feedback that the bolts drive out
E330
E330 Bolt drive in
Feedback that the bolts drive in
E331
E331 Resend control E/A
If „ 0 „ then resend operation
E332
E332 Resend control UP
If „ 1“ then UP
E333
E333 Resend control Down
If „1“ then DOWN
E334
Code key of car call 1
Code- button-1
E335
Code key of car call 2
Code- button-2
E336
Code key of car call 3
Code- button-3
E337
Code key of car call 4
Code- button-4
E338
Code key of car call 5
Code- button-5
E339
Code key of car call 6
Code- button-6
E340
Code key of car call 7
Code- button-7
E341
Code key of car call 8
Code- button-8
E342
Code key of car call 9
Code- button-9
E343
Code key of car call 0
Code- button-0
E344
E344 Code lock of car calls #
Input confirming
E345
E345 Light barrier Door 1
Entrance function light barrier Door 1
E346
E346 Reversing contact Door 1
Entrance function reversing Door 1
E347
E347 Limit switch open Door 1
Entrance function limit switch open Door 1
E348
E348 Limit switch close Door 1
Entrance function limit switch close Door 1
E349
E349 Light barrier Door 2
Entrance function limit barrier Door 2
E350
E350 Reversing contact Door 2
Entrance function reversing contact Door 2
E351
E351 Limit switch open Door 2
Entrance function limit switch open Door 2
E352
E352 Limit switch close Door 2
Entrance function limit switch close Door 2
E353
E353 Case of fire reset
Function of the Swiss fire drop evacuation, BF-> normal operation
E354
E354 floor gong off
Function for external switching of the floor gong, high gong off
E355
E355 position motor off (Hydr OTIS)
Switch off for position motors of OTIS hydraulic
E356
E356-Contactor Monitor No.2
Is a AND connection with Input E13
E357
E357 Group off
E358
E358 Engine temperature rise
If „1“ then OK
E359
E359 Door 1 open
If „1“ then the door opens (Auxiliary entrance for traffic light circuit)
E360
E360 Door 2 open
If „1“ then the door opens (Auxiliary entrance for traffic light circuit)
E361
E361 slowly drive V1
If „1“ then drives elevator only with V1
E362
E362-Control & Light off #2
Rest-Driven, like E16
E363
E363 Gas trip
If „ but wait 1” then gas trip, like interior preference/ advantage to light
barrier
E364
E364 Bolt manually drive in
Only with Insp/ releveling+ mobile bolting device
E365
E365 Bolt manually drive out
Only with Insp/ releveling+ mobile bolting device
E366
E366 Bolt Under pressure
If „ 0 „ then negative pressure
E367
E367 Bolt pressure swich off
If „0 „ then negative pressure
E368
E368 Call Blockade Inside D1 St.01
E369
E369 Call Blockade Inside D1 St.01
E370
E370 Call Blockade Inside D1 St.01
E371
E371Call Blockade Inside D1 St.01
E372
E372Call Blockade Inside D1 St.01
E373
E373Call Blockade Inside D1 St.01
E374
E374Call Blockade Inside D1 St.01
E375
E375Call Blockade Inside D1 St.01
E376
E376Call Blockade Inside D1 St.01
E377
E377Call Blockade Inside D1 St.01
E378
E378Call Blockade Inside D1 St.01
E379
E379Call Blockade Inside D1 St.01
E380
E380Call Blockade Inside D1 St.01
E381
E381Call Blockade Inside D1 St.01
E382
E382Call Blockade Inside D1 St.01
E383
E383Call Blockade Inside D1 St.01
E384
E384Call Blockade Inside D2 St.01
E385
E385Call Blockade Inside D2 St.02
E386
E386Call Blockade Inside D2 St.03
E387
E387Call Blockade Inside D2 St.04
E388
E388Call Blockade Inside D2 St.05
E389
E389Call Blockade Inside D2 St.06
E390
E390Call Blockade Inside D2 St.07
E391
E391Call Blockade Inside D2 St.08
E392
E392Call Blockade Inside D2 St.09
E393
E393Call Blockade Inside D2 St.10
E394
E394Call Blockade Inside D2 St.11
E395
E395Call Blockade Inside D2 St.12
