KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 183 -
E396Call Blockade Inside D2 St.13
E397Call Blockade Inside D2 St.14
E398Call Blockade Inside D2 St.15
E399Call Blockade Inside D2 St.16
E400Call Blockade Outside D1St.01
E401Call Blockade Outside D1 St.02
E400Call Blockade Outside D1 St.03
E403Call Blockade Outside D1 St.04
E404Call Blockade Outside D1 St.05
E405Call Blockade Outside D1 St.06
E406Call Blockade Outside D1 St.07
E407Call Blockade Outside D1 St.08
E408Call Blockade Outside D1 St.09
E409Call Blockade Outside D1 St.10
E410Call Blockade Outside D1 St.11
E411Call Blockade Outside D1 St.12
E412Call Blockade Outside D1 St.13
E413Call Blockade Outside D1 St.14
E414Call Blockade Outside D1 St.15
E415Call Blockade Outside D1 St.16
E416Call Blockade Outside D2 St.01
E417Call Blockade Outside D2 St.02
E418Call Blockade Outside D2 St.03
E419Call Blockade Outside D2 St.04
E420Call Blockade Outside D2 St.05
E421Call Blockade Outside D2 St.06
E422Call Blockade Outside D2 St.07
E423Call Blockade Outside D2 St.08
E424Call Blockade Outside D2 St.09
E425Call Blockade Outside D2 St.10
E426Call Blockade Outside D2 St.11
E427Call Blockade Outside D2 St.12
E428Call Blockade Outside D2 St.13
E429Call Blockade Outside D2 St.14
E430Call Blockade Outside D2 St.15
E431Call Blockade Outside D2 St.16
E432 Phase reversal monitoring
If „1“ ok, if “0” then errors
E433 Brake- & Blockvoltage
If „1“ ok, if “0” then errors
If „1“ ok, if “0” then errors
During active entrance to ER is switched off external control
E436 LED matrix out of operation
During active entrance LED matrix becomes to ER power down
E438 Brake open monitor 2. coil
E439 Brake open monitor 3. coil
E440 Car Elevator Photocell D1
Car Elevator Photocell in the car for Car position
E441 Car Elevator Photocell D2
Car Elevator Photocell in the car for Car position
E442 Car Elevator Photocell Middle
Car Elevator Photocell in the car for Car position
E443- Lobbymonitor D1-F 01
E444- Lobbymonitor D1-F 02
E445- Lobbymonitor D1-F 03
E446- Lobbymonitor D1-F 04
E447- Lobbymonitor D1-F 05
E448- Lobbymonitor D1-F 06
E449- Lobbymonitor D1-F 07
E450- Lobbymonitor D1-F 08
E451- Lobbymonitor D2-F 01
E452- Lobbymonitor D2-F 02
E453- Lobbymonitor D2-F 03
E454- Lobbymonitor D2-F 04
E455- Lobbymonitor D2-F 05
E456- Lobbymonitor D2-F 06
E457- Lobbymonitor D2-F 07
E458- Lobbymonitor D2-F08
E459-Controlercabinet Door Open
High signal, if the door is open
E460 Controlercabinet Door Open Invers
Low signal, if the door is open
High signal for Waiting (Door Open Command)
Normal Travel with Battery / USV are possible
If there is a pulse, then switch ON
