KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 184 -
If there is a pulse, then switch OFF
During the high signal, the door is closing and after that it starts up.
During the high signal, the door is closing and after that it starts down.
E467 Attendant Mode Land.Con.Off
Toggle-Input for switching off the landing Control
When the input is high, then Send-Controlling
When "1" then all adjacent calls cleared
When "1" then the door lock function is turned off, if active
Highsignal for the Blink Output
Additional contactor monitoring chain via normally open contacts
By using the Weight Watcher Henning load-measure-systems the er-
ror rope stretching can be evaluated by the controller.
E 476 Startdelay UP & Down
Function for the Acceleration
If the input is active the controller is transferred to the dead man
mode.
Input for Universal-Output-5
Input for Universal-Output -6
Input for Universal-Output -7
Input for Universal-Output -8
Input for Universal-Output -9
Input for Universal-Output -10
Input for Universal-Output -11
Input for Universal-Output -12
Input for Universal-Output -13
Input for Universal-Output -14
Input for Universal-Output -15
Input for Reset the time relay 1
Input for Reset the time relay 2
Landing calls are not accepted
E492 Temerature Heat Travel
Thermostat input for the heating function
Input channel for the EN81-A3 Function for UCM-Status 1
Input channel for the EN81-A3 Function for UCM-Status 2
Input channel for the EN81-A3 Function for UCM-Status 3
Synchronous monitoring channel 1 of the TV60-1
Synchronous monitoring channel 2 of the TV60-1
FRAPORT – Safety system OSKAR
FRAPORT – Safety system OSKAR
FRAPORT – Safety system OSKAR
FRAPORT – Safety system OSKAR
When the level is „1“ then the fill-operation is active.
When the level is „1“ then the empty-operation is active.
Synchronous monitoring channel 1 of the TV60-2
Synchronous monitoring channel 2 of the TV60-2
E506 RESET Brake monitoring
Possibility of external reset during braking control elements and A3
case.
E507 Battery monitoring 1
Monitoring of the battery of EOS or other units
E508 Battery monitoring 2
Monitoring of the battery of EOS or other units
Function for Monitoring the rubber skirt
E510 Fire Sensor Floor 01 Door 2
Input for Fire Evaquation - Fire Sensor Floor 01 Door 2
E511 Fire Sensor Floor 02 Door 2
Input for Fire Evaquation - Fire Sensor Floor 02 Door 2
E512 Fire Sensor Floor 03 Door 2
Input for Fire Evaquation - Fire Sensor Floor 03 Door 2
E513 Fire Sensor Floor 04 Door 2
Input for Fire Evaquation - Fire Sensor Floor 04 Door 2
E514 Fire Sensor Floor 05 Door 2
Input for Fire Evaquation - Fire Sensor Floor 05 Door 2
E515 Fire Sensor Floor 06 Door 2
Input for Fire Evaquation - Fire Sensor Floor 06 Door 2
E516 Fire Sensor Floor 07 Door 2
Input for Fire Evaquation - Fire Sensor Floor 07 Door 2
E517 Fire Sensor Floor 08 Door 2
Input for Fire Evaquation - Fire Sensor Floor 08 Door 2
E518 Door 1 Manual Opening
Input channel for Door 1 Manual Opening
E519 Door 1 Manual Closing
Input channel for Door 1 Manual Closing
E520 Door 2 Manual Opening
Input channel for Door 2 Manual Opening
E521 Door 2 Manual Closing
Input channel for Door 2 Manual Closing
E522 Hazardous Transport Off
Input function to switch off the Hazardous Transport
Input channel for Reset function Door is Ready
Input channel for monitoring the relay function of K69
Input channel for the car light sensor to monitor the car light
E526 Car Preference Call Pulse
E527 Car Preference Call Release
Inspection ON / OFF in the pit, „0“=ON / „1“ = OFF
