KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 45 -
2.13 DESCRIPTION CONTROLLING-VALVE RV-60-102 & NGV60-101
RV-60-102
The assembly RV-60-102 is used to monitor
the control
chart of the type AZRS company ALGI and LRV-DELCON
of the company Bucher.
The configuration is done through the insertion of the relay
K34A for ALGI and by setting the jumper for Bucher.
The connection to the cenral-unit ZR is done by a 9-pole D-
Sub-cable.
Also,
the module has the outputs for the drive commands
and directions.
NGV60-101
The module NGV60-101 is used to monitor
the control
block GMV Oildynamic NGV A3. The configuration
is done
by setting the DAVID control system.
The connection to the ZR-DAVID unit is done by a 9 pin D-
sub-assembly Cable. The module provides the
driving
command, direction, feedback and UCM-valve control.
Earth
Speed
-Releveling
Run
-
In Speed Vo
Half Speed V1
Half Speed V2
Full Speed V3
Speed Inspektion
Direction Up
Direction Down
0V GND
PE
Vn
V0
V1
V2
V3
Vi
AF
AB
0V
Half Speed
Ö6
Half Speed
B6
Delay Up-Command
S2
Delay Up-Command
S1
D-Sub-9 Controlling Valve RV60-102
Run-In Speed
G0
0V GND
B12
Quick Up
B1
Slow Up
B2
Quick Down
B3
Slow Down
B4
Bucher Inspection
B5
ALGI Inspection
G5
K31A
K32A
K33A
K35A
K34A
K36A
LED Up
LED Down
LED Quick
LED Inspection
LED Slow
LED Half Sppeed
UCM
-Status 1
UCM
-Status 2
Less Pressure
Overpressure
Overload
free programable
Conroller Voltage +24V
VSMA
-Valve
VMD Down Valve
VSMA
-Valve
VMD Down Valve
161
162
171
172
173
174
200
721
722
723
724
D-Sub-9 Controlling Valve NGV60-101
161
200
162
200
171
172
173
174
0V
Auf
V2 V1
Vi
200 500 721 722 723 724
0V GND
Direction Up
Speed V2
Speed V1
Speed Vi
Controller Voltage +24V
0V GND
VSMA
-Valve
VMD Down
-Valve
VSMA
-Valve
VMD Down
- Valve
