KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 55 -
B23-Car Priority
Floor Calls
erase, store
erase
Mail Travel
Off, On
off
Input logic input E186 :
negative / positive
negative
Door position
1 open, 2 open, 3 open, 1+2 open
1+2 open
B24-Landing Priority
Time call Input
10 to 600 sec
20 sec
Floor Calls
erase,store
erase
Priority Car Call
individual
individual
Collective
Soft individual
Individual empty
Individual and soft
Collective, EA67 empty
Collective-1
Collective, EA67 targ
Priority Car Call: Floorcall-5sec:
Off / A1, A2
Off
Hazardous Material Transport
Off/ On-1, On-2
Off
Hazardous Material Transport Cabin
Off, On-1 / On-2
Off
B25 Groupcontroller
Door Failure
10 to 60 sec
After 60 sec
ER-IN/OUT 2xC
Free programmable Groupfunction
G01 Call Door-2 UP
ER-IN/OUT 2xD
Free programmable Groupfunction
G02 Call Door-2 DOWN
ER-IN/OUT 97A
Free programmable Groupfunction
G04 priority A1-3-5-7
ER-IN/OUT 98A
Free programmable Groupfunction
G05 priority A2-4-6-8
ER-IN/OUT 97B
Free programmable Groupfunction
G04 priority A1-3-5-7
ER-IN/OUT 98B
Free programmable Groupfunction
G05 priority A2-4-6-8
Parking Zone-1: to Parking Zone-5
Off, ON, Priority 1,.. Priority 5
Off
Parking Zone-1: to Parking Zone-5
Always active/ Timer 1 - Timer 10
Always
Parking Zone-1: Bottom Floor
1 to 2
Parking Zone-1: Top Floor
1 to 64
Parking Zone-5: Bottom Floor
1 to 2
Parking Zone-5: Top Floor
1 to 64
Group Dynamic Travel Time Floor
Auto, 0 to 10 sec
3,0 Sec.
Group Dynamic Stop Time Floor
Auto, 0 to 25 sec
8,0 Sec.
Group Dynamic Call Sharing
Dynamic / Engery
Dynamic
Output HEX5-Code ER-EA7/8
No, Yes
Off
B3-DRIVE
B30 Hydraulic Not Regulated
Start
Star/Delta , Softstart
Softstart
S/D-Reverse Time
0,1 to 4,0 sec
2 sec
Direction Up Delayed On
No,Yes –10 to 900 ms.
100 ms
Direction Up Delayed Off
No,Yes –10 to 4000 ms.
400 ms
Start with Door Controlling
No,Yes –1 to 3 sec. delayed
No
Inspection Speed
Slow, Quick
slow
Time to go Down
Off, 1 to 15 Minuten
10 Min.
Fault Handling
No,Yes – interrupt + godown, block,
block 2.attempt
No
Travel down at Overload
No,Yes
No
Signal Top of Ramp
No,Yes
Yes
Command Down Delay. On
No,Yes 10 to 900 ms.
Yes
Command Down Delay. Off
No, Yes 10 to 1500 ms.
Yes
Lock after End-Switch Top
No, Yes
Yes
Liftbus
OFF, KW-Bus, DCP-3
KW BUS
Warm Up travel
OFF, Always active, active on E492
OFF
Warm Up travel after Time
Minutes 5 to 1250
B31 Hydraulic Regulated
Start
Star/Delta , Softstart
Softstart
S/D-Reverse Time
0,1 to 4,0 Sek.
2 sec
Direction Up Delayed On
No,Yes –10 to 900 ms.
100 ms
Direction Delayed On
No,Yes –10 to 900 ms
Direction Up Delayed Off
No,Yes –10 to 4000 ms.
No
Start with Door Controlling
No,Yes –10 to 2000 ms.
400 ms
Start with Door Controlling
No,Yes –1 to 3 sec. delayed
No
Leveling Speed
V0, Vn
