KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 54 -
LG-monitoring Input
Not Inverted/Inverted
Photocell Door Open By Hand
No / Yes
No
B13-Nudging Function
Nudging
Off, On 1 to 180 sec
Off
Nudging Signal
Door-close & A192/193 / only A192/3
Door-close & A192/193
B14-Entrance Monitor
Entrance Monitor
No,Yes
No
Time a. st. Door-1
0,5 to 10 sec, always active
2 sec
Time a. st. Door-2
0,5 to 10 sec, always active
2 sec
Time a. st. Door-3
0,5 to 10 sec, always active
2 sec
Entrance Monitor
Not Inverted/Inverted
Inverted
B15-Mech. Lock
Pulse Buf. Delay
50 ms to 2000 ms
500 ms
Lock Delay ON
0,0 to 5,0 sec
0 sec
Lock Delay OFF
0,0 to 9,9 sec
0 sec
Lock Handdoor
After Cardoor, Before Cardoor
After Cardoor
Open after lock
0,0 to 9,9 sec
0 sec
Mechanical Lock-OFF
10 to 720 Seconds
30 Seconds
Mechnaical Lock Control
Normal / Inverted
Normal
Additional Lock delay
0,5 to 5,0 sec
1,0 sec
B16-Safety-Circuit
Pre-Opening Doors
No,Yes
No
Early Premagn.
No,Yes
No
Early Premagn. delay
00,8 – 10,0 sec
Safety Circuit
SIS-60 / SIS-16
SIS-16 (KW)
B17 Releveling
Releveling
No,Yes
No
No Releveling Distance
5 to 50mm
10 mm
Max. Releveling Distance
10 to 250mm
100 mm
Leveling-UP
-48 to 0mm
0 mm
Leveling-DOWN
0 to 48mm
0 mm
Time Limit
3 to 25 sec
20 sec
Attempt Limit
3 to 25
20
Limit at Level 1
Releveling, No Releveling
No Limit
Overload
Releveling, No Releveling
Releveling
Fault Handling
Block / Error log, no block
X
Finereleveling
No / Yes, ALGI, BUCHER
No
Buzzer-Alert
if not leveling: No, Yes
Yes
B2-Call Options
B21 Car Calls
Door Reverse Car Call
Off,On
Off
Selectiv Car Calls
No,Yes
No
Callreset/ Error
immediatly, 1 to 10 sec
4 sec
Car Call CPU
Without FKR+EIT, KKR+EIT-IC..IU
active, FKR+EIT-IC..IE active
EIT aktiv
Car Call Limit
OFF, 2 to max.floor call reset
Off
Misure Defence
No, Yes
No
Button-Buzzer
No, Yes
Off
Car Call Range
Off, 1-2/ 1-3/ 1-4/ 1-5/ 1-6/ 1-7/
Off
Automatic Car Call Vehicle
Off
Off
Deselect call
By double click: No / Yes
B22-Landing Calls
Door Reverse Landing Call
Off,On
Off
Modul
Central-Unit, Level-Unit
ZR
Selectiv Landing Calls
No,Yes
No
Erase operative Calls
No,Yes
No
Save Travel Direction
1 to 20 sec
5 sec
Floor Indicator Blink
Off, On
Off
Button Call-UP Buzzer
Off,On (1x, 2x)
Off
Button Call-DOWN Buzzer
Off,On (1x, 2x)
Off
Side separation by floorcall
Off, On
Off
Side separation save floorcall
Off, On
Off
Buzzer active if indication on:
No, Yes
Off
Abuse protection 2 pushbuttons
Off, On
Off
Destination dialing if indication on:
No, Yes
