KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 53 -
Handdoor w. Cardoor with Limit SW
Handdoor no Cardoor
No Door
Automatic + SW Open
Automatic + SW Close
Hand/Cargo. + SW Open
Hand/Cargo. + SW Close
Limit-SW door-3
Inverted/ Not Inverted
Inverted
Doorengine active
Always on / standby off / door-closed
standby off
Standby off
Doorengine 2 active
Always on / standby off / door-
closed
standby off
Standby off
Doorengine 3 active
Always on / standby off / door-
closed
standby off
Standby off
Shaftdoor Waiting
0,1 to 2,0 Sek.
0,5 sec
Cardoor Waiting
0,1 to 2,0 Sek.
0,5 sec
Later Door Opening
0,0 to 2,0 Sek.
0,5 sec
Limited Door Opening
No, Yes 1,0 to 10 Sek.
6 sec
Door Open Timeout
No, Yes 1,0 to 60 Sek.
13 sec
Door Close Timeout
No, Yes 1,0 to 60 Sek.
20 sec
Further Travel Delay Car Call
Selectiv, 1,0 bis 60
7 sec
Further Travel Delay Landing Call
Selectiv, 1,0 bis 60
9 sec
F. Del. C-C mainf
Selectiv, 1,0 bis 60
7 sec
F. Del. L-C mainf
Selectiv, 1,0 bis 60
9 sec
Door Open trig.
No,Yes
No
Door Rev. Delay
Generel 0 to 1000 ms
500 ms
Dooreng. Stb. off
Selectiv, 1 to 60 sec
10 sec
Dooringine-2 stand-by off
Selectiv, 1 to 60 sec
10 sec
Dooringine-3 stand-by off
Selectiv, 1 to 60 sec
10 sec
Door standy
Open, Close 1 to 60 sec
open
Door stby. Main.
Open, Close 1 to 60 sec
open
Door Control Inspection
Yes, No
Yes
Button Door op.
Together, Selectiv together, Separate, Selectiv separate
Button Holdtime
No, button ON-OFF 2,0 to 5400 Sec
No
Button Holdtime Function
Separate/ Together/ Auto w.photocell/ Auto with photocell 1-5s / Separate, trigger
Button Door Close Function
Separate, Together, Selectiv together
Together
Button Door Close Reaction
0,0 to 5,0 sec
2 sec
Door Control Atemps
1 to 10 attempts
3
Door Open Time
1 to 60 sec
2 sec
Door-Opening
Normal-Function /Only Door-Open-
Button
Normal Function
Door-Closing
Normal-Function /Only Door-Close-
Button
Normal Function
B11 Table of Entrance
Door-1 Door-2 Door-3
Door-1 Door-2 Door-3
Floor -01
Existing Yes or No
…............../….............
…............../….............
Floor -02
Existing Yes or No
…............../….............
…............../….............
Floor -03
Existing Yes or No
…............../….............
…............../….............
Floor -04
Existing Yes or No
…............../….............
…............../….............
Floor -05
Existing Yes or No
…............../….............
…............../….............
Floor -06
Existing Yes or No
…............../….............
…............../….............
Floor -07
Existing Yes or No
…............../….............
…............../….............
Floor -08
Existing Yes or No
…............../….............
…............../….............
Floor -09
Existing Yes or No
…............../….............
…............../….............
Floor -10
Existing Yes or No
…............../….............
…............../….............
Floor -11
Existing Yes or No
…............../….............
…............../….............
Floor -12
Existing Yes or No
…............../….............
…............../….............
Floor -13
Existing Yes or No
…............../….............
…............../….............
Floor -
Existing Yes or No
…............../….............
…............../….............
Floor -64
Existing Yes or No
…............../….............
…............../….............
B12-Safety Photocell
Safety Photosell
Off/ On / CEDES / Duometric
Off
Photocell- Monitor
Off, On 1 to 600 sec
60 sec
Ramp Travel
Off,ON
Off
Door Close del.
Off, On 1 to 10 sec
2 sec
Photocell Input
Not Inverted/Inverted
Inverted
Reverse Contact
Not Inverted/Inverted
Inverted
