Short travels
No/1 ,2 ,3 ,4 ,5 ,6 ,7 ,8 short tr.
No
If 1 Short-drive-> Short-drive-1 between
1<->2, 2<->3, 3<->4 ,......
If 2 Short-drive-> Short-drive-2 between
1<->2, 2<->3, 3<->4 ,......
If 3 Short-drive-> Short-drive-3 between
1<->2, 2<->3, 3<->4 ,......
If 4 Short-drive-> Short-drive-4 between
1<->2, 2<->3, 3<->4 ,......
If 5 Short-drive-> Short-drive-5 between
1<->2, 2<->3, 3<->4 ,......
If 6 Short-drive-> Short-drive-6 between
1<->2, 2<->3, 3<->4 ,......
If 7 Short-drive-> Short-drive-7 between
1<->2, 2<->3, 3<->4 ,......
If 8 Short-drive-> Short-drive-8 between
1<->2, 2<->3, 3<->4 ,......
Distance Prel. SW-ZSW
To Measure in mm
1000 mm
Decel. Spd V0=>0 Travel up
Distance in mm
5 mm
Decel. Spd V0=>0 Travel down
Distance in mm
5 mm
Decel. Spd V1 Travel up
Distance in mm
500 mm
Decel. Spd V1 Travel down
Distance in mm
500 mm
Decel. Spd V2 Travel up
Distance in mm
1000 mm
Decel. Spd V2 Travel down
Distance in mm
1000 mm
Decel. Spd V3 Travel up
Distance in mm
1500 mm
Decel. Spd V3 Travel down
Distance in mm
1500 mm
Learn Drive
Start with V1, V2, V3
V1
Travel by V0
If distance < 200mm
Travel by V1
If distance < 200mm
Travel by V2
If distance < 200mm
Slowdown-direction DOWN to V1
Off, On 100 - 15000mm
Slowdown-direction UP to V1
Off, 100 - 15000mm
Encoder Termin.
At ZR/FKR
ZR
Learn Drive Activate
No, Yes
No
Switch Hysteres Overlapping
Xxx mm
0 mm
Leveling by car-panel
No
Level. Floor-01 lev. Value
Bündig-value: 000,000 m
000,000 m
Level. Floor-64 lev. Value
Bündig-value: xxx,xxx m
xxx,xxx m
B43 Absolut Copy
CANopen-system
Variotech ANTS
Variotech ANTS safe
LIMNAX33CP safe
Rotary encoder
Pulse Buffer Delay
2 to 50 ms
2 ms
Distance-system
Schmersal-USP / Wachendorff
Floorswitches
no/ prelevel+floorswitch / only floorswitch
Floorswitches
Zone 71+72 external / Zone 72 simulation
Short travels
No/1 – 8 short travels
No
If 1 Short-drive-> Short-drive-1 between
1<->2, 2<->3, 3<->4 ,......
If 2 Short-drive-> Short-drive-2 between
1<->2, 2<->3, 3<->4 ,......
Decel. Spd V0=>0 Travel up
Distance 1 – 1000 mm
5 mm
Decel. Spd V0=>0 Travel down
Distance 1 - 1000 mm
5 mm
Decel. Spd V1 Travel up
Distance in mm
500 mm
Decel. Spd V1 Travel down
Distance in mm
500 mm
Decel. Spd V2 Travel up
Distance in mm
1000 mm
Decel. Spd V2 Travel down
Distance in mm
1000 mm
Decel. Spd V3 Travel up
Distance in mm
1500 mm
Decel. Spd V3 Travel down
Distance in mm
1500 mm
Travel by V0 if distance
< 10 – 200 mm
Travel by V1 if distance
< 200 – 300 mm
Travel by V2 if distance
< 200 – 9999 mm
Slowdown-direction DOWN to V1
Off/ 100 – 15000 mm
Slowdown-direction UP
Off/ 100 – 15000 mm
Encoder Terminal
at Car-CPU (FKR)/ Central-CPU (ZR)
Countdirection
Positiv
Positiv
Learn Drive
V1, V2, V3 execute
V1
Learn Drive activate
No,Yes
No
Way Recognation Learning
No,Yes
No
Synchronisation Floor-8
No,Yes
No
Level Mode
Floor level// floor distance
Leveling by Car-panel
No
Level. Floor-01 lev. Value
Levelvalue: 000,000 m
000,000 m
Level. Floor-64 lev. Value
Levelvalue: xxx,xxx m
xxx,xxx m
