KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 58 -
B44 Motor Copy
Pulse Buf. Delay
2 to 150 ms
2 ms
Correct. Travel
After call / automatic
After call
2nd Prel. SW bot
No,Yes ER-Speaker
No
2nd Prel. SW top
No,Yes ER-Speaker
No
Short travels
No/1 ,2 ,3 ,4 ,5 ,6 ,7 ,8 short tr.
No
If 1 Short-drive-> Short-drive-1 between
1<->2, 2<->3, 3<->4 ,......
If 2 Short-drive-> Short-drive-2 between
1<->2, 2<->3, 3<->4 ,......
If 3 Short-drive-> Short-drive-3 between
1<->2, 2<->3, 3<->4 ,......
If 4 Short-drive-> Short-drive-4 between
1<->2, 2<->3, 3<->4 ,......
If 5 Short-drive-> Short-drive-5 between
1<->2, 2<->3, 3<->4 ,......
If 6 Short-drive-> Short-drive-6 between
1<->2, 2<->3, 3<->4 ,......
If 7 Short-drive-> Short-drive-7 between
1<->2, 2<->3, 3<->4 ,......
If 8 Short-drive-> Short-drive-8 between
1<->2, 2<->3, 3<->4 ,......
Distance Prel. SW-ZSW
To Measure in mm
1000 mm
Decel. Spd V0=>0 Travel up
Distance in mm
5 mm
Decel. Spd V0=>0 Travel down
Distance in mm
5 mm
Decel. Spd V1 Travel up
Distance in mm
500 mm
Decel. Spd V1 Travel down
Distance in mm
500 mm
Decel. Spd V2 Travel up
Distance in mm
1000 mm
Decel. Spd V2 Travel down
Distance in mm
1000 mm
Decel. Spd V3 Travel up
Distance in mm
1500 mm
Decel. Spd V3 Travel down
Distance in mm
1500 mm
Learn Drive
Start with V1, V2, V3
V1
Travel by V0
If distance < 200mm
Travel by V1
If distance < 200mm
Travel by V2
If distance < 200mm
Slowdown-direction DOWN to V1
Off, On 100 - 15000mm
Slowdown-direction UP to V1
Off, 100 - 15000mm
Encoder Termin.
At ZR/FKR
ZR
Learn Drive activate
No,Yes
No
Switch-hysterese overlapping
Xxx mm
0 mm
Leveling by car-panel
No
Level. Floor-01 lev. Value
Bündig-value: 000,000 m
000,000 m
Level. Floor-64 lev. Value
Bündig-value: xxx,xxx m
xxx,xxx m
B45 Minimum Copy
Pulse Buf. Delay
10 to 150 ms
50 ms
Correct. Travel
After call / automatic
After call
B46 R&S copy
Pulse Buf. Delay
10 to 150 ms
50 ms
Correct. Travel
After call / automatic
After call
B5-Indicate
B501 Car Indicatation
Cabine Code
Binary / 1 of N / gray / 7-Segment / free selection/ binary-0
Main-CPU Code
Binary / 1 of N / gray / 7-Segment /
Floor-CPU Code
Binary / 1 of N / gray / binary-0 / 1 of N floor level
Code 7-Segment
Setup for every Floor
U,H,F,E,d,C,b,A,1,2,3,4,5,6,7,8,9
Code select
Setup for every Floor, 0 – 11111111b
0000 0000 b
Special Mode Inspect./ manual
ON / OFF
ON
Special Mode error case
ON / OFF
ON
Special Mode spezial travel
ON / OFF
ON
Special Mode Attendant Mode
ON / OFF
ON
B502 Car Arrow
Description
Only move on
Direction & move on
Only direction
M-Arrow-OFF
No,Yes after 1 to 60 sec
No
M-A.Door close
No,Yes
Yes
B503 Floor Arrow
Arrows
No,Yes – ZR , ER, EAT
No
ZR: Description
Only move on
Direction & move on
Only direction
ZR:M-Arrow-Off
No,Yes after 1 to 60 sec
No
