KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 59 -
ER: Description
Only direction
X
Direction+ move on
Only move on
ER: ER:M-Arrow-Off
No,Yes 1 to 60 sec
No
M-A. Door close
No,Yes
Yes
B504 Gong At The Car
Gongfunction
No,Yes FKR-speaker/ TFT-speaker/
FKR+TFT-speaker
No
Car Call UP
No,one ring,double ring,triple ring
No
Car Call DOWN
No,one ring,double ring,triple ring
No
Floor Call UP
No,one ring,double ring,triple ring
One ring
Floor Call DOWN
No,one ring,double ring,triple ring
Double ring
Priority Call UP
No,one ring,double ring,triple ring
No
Priority Call DOWN
No,one ring,double ring,triple ring
No
Fire Fighter Tr.
No,one ring,double ring,triple ring
No
Special Travel
No,one ring,double ring,triple ring
No
Gongfunction Volume-TFT
1 to 100 %
Gongfunction Volume-FKR
1 to 100 %
Gongfunction Tone
1 to 100 %
B505 Gongfunction At The Floor
Gongfunction
No,Yes ER-Speaker, TFT-Speaker,
ER+TFT-Speaker
No
Car Call UP
No,one ring,double ring,triple ring
No
Car Call DOWN
No,one ring,double ring,triple ring
No
Floor Call UP
No,one ring,double ring,triple ring
One ring
Floorcall DOWN
No,one ring,double ring,triple ring
Double ring
Priority Call UP
No,one ring,double ring,triple ring
No
Priority Call DOWN
No,one ring,double ring,triple ring
No
Fire Fighter TR.
No,one ring,double ring,triple ring
No
Special Travel
No,one ring,double ring,triple ring
No
Gongfunction Volume-TFT
1 to 100 %
7
Gongfunction Volume-ER
1 to 100 %
Gongfunction Tone
1 to 100 %
7
Output ER puls
Short puls, 1 - 10 sec
Short puls
B506 LED-Matrix
Car Display Arrow
No,Yes,Scroll
Scroll
Car M-arrow
Blink, fixed
Car Floor Animation
Fixed / Scroll / Trick 1
Scroll
Car Display Segments
1 / 2 / 3
3
Floor Display Arrow
No,Yes,Scroll
Scroll
Floor Floor Animation
Fixed / Scroll / Trick 1
Scroll
Floor Segments
1 / 2 / 3
2
FLOOR INDICATOR LIGHT
Off / out of order / special travel / occupied / out of order + special
Main Unit Display
1 to 64 / like in car
1 to 64
B507 Floor Display
Floor-01 Display:
HS-01
HS-17
HS-33
HS-49
Floor-02 Display:
HS-02
HS-18
HS-34
HS-50
Floor-03 Display:
HS-03
HS-19
HS-35
HS-51
Floor-04 Display:
HS-04
HS-20
HS-36
HS-52
Floor-05 Display:
HS-05
HS-21
HS-37
HS-53
Floor-06 Display:
HS-06
HS-22
HS-38
HS-54
Floor-07 Display:
HS-07
HS-23
HS-39
HS-55
Floor-08 Display:
HS-08
HS-24
HS-40
HS-56
Floor-09 Display:
HS-09
HS-25
HS-41
HS-57
HS-10
HS-26
HS-42
HS-58
HS-11
HS-27
HS-43
HS-59
HS-12
HS-28
HS-44
HS-60
HS-13
HS-29
HS-45
HS-61
HS-14
HS-30
HS-46
HS-62
………
HS-15
HS-31
HS-47
HS-63
Floor-64 Display:
HS-16
HS-32
HS-48
HS-64
B508 Messages
Overload
Car: * Floor: -
Car: Floor:
Evacuation
Car: * Floor: -
Car: Floor:
Fire Evacuation
Car: * Floor: -
Car: Floor:
