KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 62 -
AW-60 Monitoring
ON, OFF
ON
Monitoring U10 floor door
Off On
ON
Monitoring DSC-Direction
ON, OFF
ON
Monitoring Nominal Speed
ON, OFF
ON
Monitoring Door switch shut
ON, OFF
ON
Monitoring U11 Car door
OFF, ON
ON
Monitoring U12 door bolt
OFF, ON
ON
Monitoring UPS
OFF, ON
ON
Lock E06 U5 speed limiter
OFF, ON
OFF
B601 Inspection Travel
Restart locking
No,Yes
No
Restart locking Door
No,Yes
No
Speed Button
No,Yes
Yes
Inspection-Stop TOP
Floor level to -500 mm
-20 mm
Inspection-Decrease TOP
-5000mm to -6000 mm
-500 mm
Inspection-Stop BOTTOM
-1000mm to +500 mm
+20 mm
Inspection-Decrease BOTTOM
+500mm to +6000 mm
+500 mm
Inspectionbulb pit
No / Yes
No
Inspectionbulb pit reset
No / Yes
No
Pit reset by 5x door lock unlatch
No / Yes
YES
Inspections call
No / Yes lowering for 100 - 3000mm
3000mm
Monitoring of Manual speed
No to 1,00 m/s
0,30 m/s
Monitoring of Inspection speed
No to 1,00 m/s
0,50 m/s
Pit-Module ERG activate
Yes / No
Yes
B602 Emergency Unit
B602 Emergency
Alert Push Button Delay
0 to 10 Sec
Alert Push Button
B603 Car Fan
B603 Car Fan
Start Of Fan
Push Button, Travel
Start Of Fan
Fan Delay
1 to 1800 sec
Fan Delay
B604 Load Mearement
B604 Load Meare-
Overload input
Not inverted/inverted
Not inverted
Load Measurem. Loadsensor FKR
No,Yes
No
Overload
10-150%
120%
Full Load
50-110%
100%
Half Load
10-100%
50%
Under Load
1-50%
10%
Save Full Load
No,Yes
No
Save Zero Load
No,Yes
No
Overload Input BIS 80
No,NPN 63=500, PNP 63=208
PNP
Underload evaluation
No,Yes / 1 / 2 / 3 / 4 Calls
No
Full load evaluation
No,Yes
No
B605 Standby Travel
Standby Travel
No,Yes
Yes
Standby Trvl. 1 Floor
Next Floor, Floor1 to 64 max.
Next Floor
Standby Trvl. 1 OFFSET
OFF, -2500 to 2500 mm
+/- xxxx mm
Standby Trvl. 2 Floor
Next Floor, Floor1 to 64max.
Next Floor
Standby Trvl. 2 OFFSET
OFF, -2500 to 2500 mm
+/- xxxx mm
Standby Travel Door
1+2 Open/closed , 1 open , 2 open, 1 open/closed, 2 open/closed, 1+2 closed
Standby Travel Floor Indicator
ON/OFF
ON
Standby Travel Car Indicator
ON/OFF
ON
B606 Parking Travel
Parking Travel
No, Yes
No
Parking Travel
Dy8-64mic
Parking Level
Floor 1 to max. Floor
Etage 2
Parking Travel Park
0 to 90 Min.
1 min
Parking Travel Door
1+2 open, 1+2 open/closed, ready
Open
B607 Floor Blocking
Floor Blocking
Input of a blocked Floors
No
Dynam. Blocking
No, carcalls/ floorcalls/ both
No
Dynam. Call Lock
Normal (1=locked), invert. (0=locked)
Normal
Dynam. Floor Lock
Normal (1=locked), invert. (0=locked)
Normal
Release C.Call Feedback
Off / Blink
OFF
Release C.Call Floor Priority
No / Yes
NO
B608 Energy saving
Car Light Automatic Off
No,Yes
No
