KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 66 -
C1-Give Calls
C10-Give Calls
Car Calls
C11-Floor Calls
Input of Floor Calls
C12-Random Car Calls
Off/ On
Off
Off after: 00,5 to 48,0 hours
8,0 hours
C13-Random Floor Calls
Off, On
Off
Off after: 00,5 to 48,0 hours
8,0 hours
C2-In/Output Signals
All In/Outputs ZR,FKR,ITR,ER
- = no Signal / * = +24V Signal
Exxx = Input Signall
Axx= Output Signal
C3-Event/Fault Log
C30 Event/Fault Log
Fault Count
C31 Logposition
Fault Position xxx
Number of Fault
Errowtext
Time xx:xx:xx
Date xx.xx.xxxx
C4-INSECTOR
C40 Run Time Test
All running times are set on 1.0 seconds for the next trip:
C41 Buffer Travel-Car
With the resend drive speed can be driven downward without delay 13B
C42 Buffer Travel-Counterweight
With the resend drive speed can be driven upward without delay 13A
C43 Claw Test
Disconnection of the short-circuit protection with the catch sample
C44 Car-/Motospeed
For the driving ability examination with MRL processor
C45 Brake Test
For MRL with electrical manual brake operation
C46 Remote Trigger Car
Start up the function remote trigger
C47 Reset Remote Trigger Car
Start up function resets remote trigger
C48 Remote Trigger Counterweight
Start up the function remote trigger Counterweight
C49 Reset Remote Trigger Counterw.
Start up the function reset remote trigger
C410 Endswitch-Travel Top
Limit switch trip UP with reduction of the V. but over driving concisely Top
C411 Endswitch-Travel Bottom
Limit switch trip Down with reduction of the V. but over driving concisely Bottom
C412 Switchcabinet Temperature-Test
Lower the temperature minimum trigger level to immediate reasing
C413 Motor-PTC-Test
C414 DSC-Puls-Encoder-Test
C415 Test Sink - Prevention
Excessive switching off the sink - prevention for immediate release
C416 Test UCM drive Off Level
Simulation of the journey from the zone with the door open to EN81-1 / 2-A3
C417 Test Brake Monitor brake 2
Excessive disconnection of the braking element software for instant monitoring trigger
C418 Brake test
Activation of the brake test and output of the braking distance in mm
C419 Test direction change counter
Test for triggering the direction change counter for suspension ropes & belts
C420 Test rope wear counter
Test for triggering the rope wear counter for carrying ropes & belts
C421 Test brake monitor brake 2
Software-based triggering of brake element monitoring on drive-2
C422 Test RESET GB pre-shutdown
Resetting the override of the overspeed governor
C423 Hydraulic Test-Drive Broken Pipe
Test Drive for testing the Broken Pipe Valve
C5-Leveling Cotrol
Expenditure of the current driving cab hoising depth in mm; Consise become with+ or- at over or under drive
C6-modul Monitor
Shaftbus 1 to 16
Shaftbus 17 to 32
Shaftbus 33 to 48
Shaftbus 49 to 64
DSC-Pulses
Revision Number
ER-Adress prog. Adress
C7 –Assembling Travel
Ignoring the SiKr entrances U3 to U12 resent option at assembly option
C8 – EVENT LOG
Messages & Events
C9 -Door Control - Manuell
C91 Tür - 1
C92 Tür – 2
C93 Tür - 3
D-Information
D1-In/Output
D2-Trip Counter
All Trips
Reset Tripcounter
Tripcounter UP
Tripcounter DOWN
Reset Tripcounter
