KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 65 -
B622 UCM - Monitoring
UCM – Device Type
OFF, KW-UCM, Wittur EOS-UCM, OG-anticreep, Dynatech-Vega
UCM - Monitoring
No, Oildynamik NGV-A3, Bucher iValve
No
B623 OSCAR - Interface
Oscar - Interface
OFF , Active
OFF
Call - Deadtime
OFF, 1 ... 600 Seconds
OFF
B624 Parking Garage
Parking Garage - Function
OFF , Active
OFF
Deadtime –Fill Mode
OFF, 1 ... 60 Seconds
30 Sec.
Deadtime –Clear Mode
OFF, 1 ... 60 Seconds
30 Sec.
B625 Traffic Capture
Traffic Capture - Function
OFF / Active
OFF
Calm Traffic
1 ... 60 Minutes
10 Min.
Calm Traffic Off after
1... 10 calls
3 calls
Calm Traffic slow drive
ON / OFF
OFF
Calm Traffic door slow
ON / OFF
OFF
B626 WLAN
WLAN Access Point
ON / OFF
OFF
AP-Password
Free
AP-SSID
Free
Controller-D613-1
AP-Channel WLAN-Channel-No.
01 to 15
01
B627 Sabbat Control
Sabbat Control
ON / OFF
OFF
Further Travel Delay Mainfloor
5 to 240 Sec.
60 Sec.
Further Travel Delay floors
5 to 240 Sec.
30 Sec.
Floor-UP 1-16
Setting of the Stopp-Points
Floor-UP 17-32
Setting of the Stopp-Points
Floor-UP 33-48
Setting of the Stopp-Points
Floor-UP 49-64
Setting of the Stopp-Points
Floor-DOWN 1-16
Setting of the Stopp-Points
Floor-DOWN 17-32
Setting of the Stopp-Points
Floor-DOWN 33-48
Setting of the Stopp-Points
Floor-DOWN 49-64
Setting of the Stopp-Points
B628 Penthouse Control
Penthouse-1
OFF / Floors 1 to 64
OFF
Penthouse-1 Door
1 / 2 / 3 Doorsides
Penthouse-1 Visitor
Call Button / Call Automatic
….
Penthouse-10
OFF / Floors 1 to 64
OFF
Penthouse-10 Door
1 / 2 / 3 Doorsides
Penthouse-10 Visitor
Call Button / Call Automatic
B629 Remote diagnostics
Function
OFF / DB
OFF
Reference run
OFF / Every day /Every Week/..
OFF
Time of day Start at 00:00 UHR
B630 Evacuation Liquid Pit
Liquid Pit
No / yes
No
Liquid Pit Floor
Next Floor / 1 to 64
2
Liquid Pit Entrance Open
1, 2, 1 + 2
1
B631 Evacuation Gas
Evacuation Gas
No / yes
No
Evacuation Gas Floor
Next floor, 1 to 64
2
Evacuation Gas Entrance Open
1, 2, 1 + 2
1
B7 Inputs / Outputs
B71 Associated Outputs
B72 Associated Inputs
B73 Assignment ER – EAx
B74 Debouncing (Pulse buf.delay)
Debouncing ZR
30 ms
Debouncing FKR
30 ms
Debouncing ER
30 ms
Debouncing ZG
30 ms
C-Diagnosis
C0-Controller Reset
Reset
Yes,No
