KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 64 -
Time Relay-1
Off/switch-on delay/off delay/off puls/on puls
Off
Time Relay-1 Delaytime
0 to 300 sec
0,5
Time Relay-1 Pulstime
0 to 300 sec
0,5
Time Relay-2
Off/switch-on delay/off delay/off puls/on puls
Off
Time Relay-2 Delaytime
0 to 300 sec
0,5
Time Relay-2 Pulstime
0,5 to 300 sec
0,5
Speed-threshold Vx
0,1 m/s to Vmax
0,8 m/s
Speed-threshold Vy
0,1 m/s to Vmax
Start-1 Timer-1 to 10
00:00 Clock
Stopt-1 Timer-1 to 10
00:00 Clock
Start-2 Timer-1 to 10
00:00 Clock
Stop-2 Timer-1 to 10
00:00 Clock
Day Timer-1 to 10
MO TU WE TH FR SA SU
Fan Switching Cabinet
Automatic delayed Temperature limit 30 to 70 degrees C - 30 degrees C
B616 Elevator Check
Interval
Off / modem / every week / every 2/3/4
Modem
Weekday
MO TU WE TH FR SA SU
Start time
xx : xx CLOCK
Test Action leveling
No,Yes
Yes
Test Action Car Light
No,Yes
Yes
Test Action Alarm Button
No,Yes
Yes
Test Action Door Open Button
No,Yes
Yes
Reaction
Only message / message and block
Only message
Floorblocking
No notice / notice blocked floor / only fixed blocking
Result
Check is o.k./ x failure
B617 Bolt
Bolt
Off/ Static/ Mobil
off
Floor Static
1 - 64
Bolt Releveling
No,Yes
No
Bolt Raising
10 - 250mm
64 mm
Bolt Final Leg
0 - 10000ms
1000 ms
Bolt Movement
5 60 sec.
60 sec.
Bolt Preassure Leg
In ms
4000 ms
Bolt GoDown Travel
No,Yes
Yes
B618 Codelock calls floor
Car Calls
No, Yes Floor 01 to max.
NO
Codeeinput floor 01 to Max.
4 digit code
B619 Attendant Mode
Attendant Mode
OFF / Activated by E463
OFF
Attendant Mode
No timer deactivated / Deactive after 1 to 30 Minutes
B620 Deadman Mode
Deadman Mode
Release by E327 / Release by Car Call
E327
Photocell Supervise
OFF / ON
OFF
Floorcall with Carcall
OFF / ON
OFF
Deadman Chimmey-Mode
OFF / ON
OFF
Door Deadman + Prefered Car
CLOSED / OPEN
B621 FAX-MODEM-DUN
Type
Off / Reimann-LTP / Fax / Modem / Fax + Modem / GSM-Modem CT63 / Safeline SL5 /
Own Number
SMS Number 1
Fax Number 1
Fax Number2
MODEM Number 1
MODEM Number 2
MODEM Password
RS232-1:
HPG / KW-Protocoll , HPG / PC & Reimann-LTP, Reinmann-LTP, HPG / PC
Error message
Off / Dial Modem-No.1 / Dial SMS-No.1
OFF
Gateway-IP
Static / Dynamic
Static
Gateway-IP
192.168.001.200
192.168.001.200
Gateway-Port
10000
10000
Gateway Password
ON / OFF
OFF
Gateway Password
xxxxxxxxxxxxxxxxxxxxxxxxxx
Router-IP
Static / Dynamic
RS232-1
HPG / Reimann / KW-Gateway
KW-Gateway
Error
No / Modem / SMS
NO
