KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 91 -
The output of the car controller conditions effected with group plants codes. An output in “the 1 of N”-
format is not possible, but the Binary code and Gray code are available. The output for arrow is se-
lectable between far trip and direction of travel arrows. The output for gong separately takes place for
both plants. At the exits 330 & 331 as well as 332 & 333 only one miniature speaker is attached. Volume
and pitch, as well as multiple gong are adjusted over the control.
Each remote station needs its own address in the system. This address is modulated with the ER-2005
over DIP switch on the PCB.
Address input remote station 1. group-bus ( for 2 elevators)
Number / Setup at the Dipp-switch
Number / Setup at the Dipp-switch
Address input remote station 2. group-bus ( for 2 elevators)
Number / Setup at the dipp-switch
Number / Setup at the dipp-switch
If you have an elevator group between 17 and 32 floors, you need a second group bus with the follow-
ing address:
Number / Setup at the dipp-switch
Number / Setup at the dipp-switch
Parameter: Group Dynamic – Travel Time Floor
In this parameter, the average travel time is specified between two floors.
Together with the holding time can be the approximate travel time for an elevator installation with the
present calls extrapolate.
Parameter: Group Dynamic – Stop Time Floor
In this parameter, the average hold time is specified in the floor.
Along with the travel time can be the approximate travel time for an elevator installation with the pre-
sent calls extrapolate.
Parameter: Group Dynamic – Call Sharing
Setting the call distribution: "dynamic" or "energy-saving"
Dynamically when hiring a standing lift is preferred for call distribution. If the setting has been selected
energy saving, tries to distribute the call to an appropriate moving elevator.
