1. GENERAL INFORMATION
1-12
MX’er 50
TORQUE VALUES
STANDARD TORQUE VALUES
Item
Torque (kgf-m)
Item
Torque (kgf-m)
5mm bolt, nut
6mm bolt, nut
8mm bolt, nut
10mm bolt, nut
12mm bolt, nut
14mm bolt, nut
0.45_ 0.6
0.8_ 1.2
1.8_ 2.5
3.0_ 4.0
5.0_ 6.0
6.0_ 8.0
4mm screw
5mm screw
6mm screw, SH bolt
6mm flange bolt and nut
8mm flange bolt and nut
10mm flange bolt and nut
0.15_ 0.4
0.3_ 0.5
0.7_ 1.1
1.0_ 1.4
2.4_ 3.0
3.5_ 4.5
Torque specifications listed below are for important fasteners.
ENGINE
Item
Q‘ty
Thread dia.(mm)
Torque (kgf-m)
Remarks
Cylinder head bolt
Clutch drive plate nut
Drive face nut
Clutch outer nut
A.C.G flywheel nut
Oil check bolt
Exhaust muffler joint lock nut
Exhaust muffler lock bolt
Spark plug
4
1
1
1
1
1
2
2
BF7X115
39
12
NH10
10
8
NC6mm
BF8X35
1.5_ 1.7
5.0_ 6.0
3.5_ 4.0
3.5_ 4.0
3.5_ 4.0
1.0_ 1.5
1.0_ 1.4
3.0_ 3.6
1.1_ 1.7
FRAME
Item
Q‘ty
Thread dia.(mm)
Torque (kgf-m)
Remarks
Steering stem nut
Swing arm nut
Rear wheel nut
Front wheel nut
Rear shock absorber upper mount bolt
Front shock absorber upper mount bolt
Front shock absorber lower mount bolt
Rear fork axle
Rear hub nut
Rear wheel shaft nut
Rear engine bracket up bolt
Rear engine bracket bolt
Engine hanger bracket bolt
1
4
4
4
1
2
2
1
4
2
1
2
1
14
10
14
14
10
10
10
14
12
32
10
10
10
6.0_ 8.0
4.0_ 5.0
6.0_ 8.0
6.0_ 8.0
3.5_ 4.5
3.5_ 4.5
3.5_ 4.5
6.0_ 8.0
6.0_ 8.0
11.0_ 13.0
3.5_ 4.5
3.5_ 4.5
4.0_ 5.0
