Inspect the wheel.
Replace if damage or bends
Always balance the wheel when a tire or
wheel has been changed or replaced.
DRIVE CHAIN SLACK
ADJUSTMENT
Before checking and/or adjusting, rotate the
rear wheels several revolutions and check
slack at several points to find the tightest
point. Check and/or adjust the chain slack
with the rear wheels in this “tightest”
position.
Place the machine on a level place.
Check drive chain slack.
Adjust if out of specification.
Drive chain slack: Approximately 30mm
Adjust drive chain slack:
Elevate the rear wheels by placing a suitable
stand under the rear of frame.
Loosen four bolts attaching rear axle hub.
• Never attempt even small repairs
to the wheel.
• Ride conservatively after
installing a tire to allow it to seat itself
properly on the rim.
Too little of chain slack will overload the
engine and other vital parts; keep the
slack within the specified limits.
