KYMCO MX'ER 50 - Front Wheel;Front Brake;Front Suspension;Steering System; Service Information

12. FRONT WHEEL/FRONT BRAKE/FRONT
SUSPENSION/STEERING SYSTEM
12-2
MX’er 50
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• Remove the machine frame covers before removing the front wheel. Jack the machine front wheel
off the ground and be careful to prevent the machine from falling down.
• During servicing, keep oil or grease off the brake drum and brake linings.
• Inspect the brake system before riding.
SPECIFICATIONS
Item
Standard (mm)
Service Limit (mm)
Radial
æ
2.0
Axial
æ
2.0
Front brake drum I.D
110
111
Front brake lining thickness
4
1.5
Tie rod length
266.5
æ
Rod-end (tie rod) angle
180
º
æ
TORQUE VALUES
Steering stem nut 6.0_ 8.0kgf-m
Swing arm nut 4.0_ 5.0kgf-m
Front wheel nut 6.0_ 8.0kgf-m
Front wheel hub nut 6.0_ 8.0kgf-m
Front shock absorber upper
mount bolt 3.5_ 4.5kgf-m
Front shock absorber lower
mount bolt 3.5_ 4.5kgf-m
Front wheel rim run out
