KYMCO MX'ER 50 - Headlight Switch; Starter Button

17. LIGHTS/ SWITCHES
17-6
MX’er 50
Wire Terminals
Resistance
Black/Red(+)_ Green(-)
26KW
Green(-)_ Black(+)
°¤
Oil Meter Operation Inspection
Measure the resistance between the wire
terminals with the float at upper position
(the oil meter is OFF).
Black/Red(+)_ Black(-)
°¤
STARTER BUTTON
Remove the center cover.
Disconnect the starter button yellow/brown
and yellow/red wires.
Check for continuity between the black and
yellow/red wires.
Color
Position
Green
Yellow/Red
FREE
PUSH
°≥
°≥
HEADLIGHT SWITCH
Remove the center cover.
Disconnect the headlight switch wire
coupler. Check for continuity between the
headlight switch wires.
Color
Position
Yellow
White
Blue
Pink
°≥
°≥
°≥
°≥
°≥
°≥
Green
Yellow/ Red
Starter Button
Yellow
Blue
White
Pink
Headlight Switch
Oil Meter
Float
B/R
Ç
Å
G
B
G
Before removing the oil meter, be sure to
drain the motor oil and do not allow
sparks or flames near the working area.
°Ø
Before performing the following test,
operate the turn signals to determine
that the battery circuit is normal.
°Ø
