INSTALLATION
Reverse the “REMOVAL” procedure.
Apply grease onto the collar, bush, pivot
shaft and thrust cover.
Install the swing arm and tightening the nut.
Torque: 6.0_ 8.0kgf-m
Install the shock absorber and tightening the
bolt.
Torque: 3.5_ 4.5kgf-m
Install the shaft, washer and cotter pin.
Install the rear hub and rear wheels.
Refer to the “REAR WHEEL
INSTALLATION” section.
Adjust the drive chain slack.
Refer to the “DRIVE CHAIN SLACK
ADJUSTMENT” section in the CHAPTER
3.
Approximately: 30 mm
