17. LIGHTS/ SWITCHES
17-1
MX’er 50
ELECTRICAL EQUIPMENT LAYOUT
Stop Switches
Ignition Switch
Ignition Switch
Headlight Switch/
Starter Button/Engine
Stop Switch
Headlight
Ignition
Switch
Taillight/Stop
Light
Ignition Switch
