5. FUEL SYSTEM
5-7
MX’er 50
Connect the auto bystarter yellow wire to
the battery positive (+) terminal and green/
black wire to the battery negative (-) terminal
and wait 5 minutes.
Connect a hose to the fuel enriching circuit
and blow the hose with mouth.
If air can be blown into the hose, the auto
bystarter is faulty and replace it with a new
one.
AUTO BYSTARTER REMOVAL
Remove the auto bystarter cover.
Remove the two auto bystarter set plate
screws to remove the auto bystarter.
Check the auto bystarter valve and needle for
wear or damage.
Check the O-ring for wear or damage.
Auto Bystarter
Screws
O-ring
Set Plate
Bystarter Valve
Bystarter
Needle
