SERVICE INFORMATION
SPECIFICATIONS
Specified Oil : GEAR OIL SAE 90#
Oil Capacity At disassembly
At change
SPECIAL TOOLS
Bearing puller/remover set, 12mm E020
Bearing puller/remover set, 15mm E018
Crankshaft assembly collar E029
Driver handle A
Crankshaft assembly shaft E016
SERVICE INFORMATION
..............................
10-1 FINAL REDUCTION INSPECTION 10-2
: :
:
140 cc
120 cc
TROUBLESHOOTING
...................................
FINAL REDUCTION DISASSEMBLY
...............
...............
BEARING REPLACEMENT
.........................
FINAL REDUCTION ASSEMBLY
..................
E014
TROUBLESHOOTING
Engine starts but motorcycle won‘t move
Damaged transmission
Seized or burnt transmission
Faulty drive belt
Faulty clutch
Abnormal noise
Worn, seized or chipped gears
Worn bearing
Oil leaks
Oil level too high
Worn or damaged oil seal
10. FINAL REDUCTION
Oil seal/Bearing driver E014
TORQUE
Transmission cover 1.2 kg-m
