14-6
14. BATTERY/CHARGING SYSTEM/
A.C. GENERATOR
A.C. GENERATOR
Fan cover
Remove the right cover.
Remove the four bolts attaching the fan cover.
Remove the fan cover.
Cooling Fan
Remove the cooling fan by removing the four
cooling fan attaching bolts.
Hold the flywheel with an universal holder.
Remove the flywheel nut.
Universal holder E017
Special
Remove the A.C. generator flywheel using the
flywheel puller.
Remove the woodruff key.
Special
Flywheel puller E002
Flywheel puller
