FRONT/REAR HANDLEBAR
COVER REMOVAL
Remove the back mirrors.
Remove five screws attaching to the rear handlebar
cover.
Remove the speedometer cable.
Disconnect the wires of the speedometer.
Remove the rear handlebar cover.
Remove two screws attaching to the back of front
handlebar cover.
Remove the bolt attaching to the front of front
handlebar cover.
Installation is in the reverse order of removal.
Remove four bolts onto the floorboard.
Remove the floorboard.
Installation is in the reverse order of removal.
If the rear handlebar cover removed, be
careful not to damage the claw.
2. EXHAUST MUFFLER/FRAME COVER
REAR HANDLEBAR COVER REMOVAL
FRONT HANDLEBAR COVER REMOVAL
FLOORBOARD REMOVAL
2-3
Movie S 125i
