7. CYLINDER HEAD/VALVES
7-7
Remove the cylinder head.
Remove the dowel pins and cylinder head gasket.
Remove the cam chain guide.
Dowel Pins Gasket
Cam Chain Guide
Remove the valve spring cotters, retainers,
springs, spring seats and valve stem seals using a
valve spring compressor.
CYLINDER HEAD
DISASSEMBLY
Be sure to compress the valve springs with
a valve spring compressor.
Valve spring compressor E040
Special
Valve spring compressor
