Side skirt
FRAME COVER
Remove two screws attaching to the left/right rear
skirt.
Remove the rear skirt.
RIGHT/LEFT SIDE SKIRT REMOVAL
Remove four screws attaching to the rear career.
Remove the rear career.
REAR CAREER REMOVAL
Remove four bolts attaching to the luggage box.
Remove the screw on the center luggage.
LUGGAGE BOX REMOVAL
Be careful not to damage the clips while removing
the body center cover.
BODY CENTER COVER REMOVAL
2-1
2. EXHAUST MUFFLER/FRAME COVER
Movie S 125i
