DTC INSPECTION PROCEDURE

Connect Fi diagnostic tool with the connector of

harness wire located beside the Battery.

19-2

Diagnostic Tool Connector

Press the " Enter " button

Check the software version

Press the " Enter " button and then turn to the first

page.

Press the " Down " button to enter the DTC Inspect.

19. Fi DIAGNOSTIC TOOL OPERATION

Movie S 125i
