BEARING REPLACEMENT
(TRANSMISSION CASE COVER)
Do not remove the transmission case cover
except for necessary part replacement.
When replacing the drive shaft, also replace
the bearing and oil seal.
Drive shaft bearing
Final shaft bearing
Countershaft bearing
Bearing puller
10. FINAL REDUCTION
Check the left crankcase bearings for excessive
play and inspect the oil seal for wear or damage.
Inspect the drive shaft and gear for wear or
damage. Check the transmission case cover
bearings for excessive play and inspect the final
shaft bearing oil seal for wear or damage.
Remove the transmission case cover bearings
using a bearing puller.
Remove the final shaft oil seal.
Drive new bearings into the transmission case
cover.
Oil seal/Bearing driver E014
Special
Oil seal/Bearing driver
Bearing puller/remover set, 15mm E018
Special
Countershaft bearing Drive shaft bearing
Final shaft bearing
Final shaft bearing
