BEARING REPLACEMENT
(LEFT CRANKCASE)
FINAL REDUCTION ASSEMBLY
Install the drive shaft into the left crankcase.
10-4
10. FINAL REDUCTION
Bearing puller, 12mm
Bearing driver
Drive shaft
Remove the drive shaft.
Remove the oil seal drive shaft.
Remove the left crankcase bearing using a bearing
puller.
Drive new bearings into the left crankcase.
Install a new drive shaft’s oil seal.
Install the final gear and final shaft into the left
crankcase.
Oil seal/Bearing driver E014
Special
Bearing puller/remover set, 12mm E020
Special
