Bolts
10. FINAL REDUCTION
Install the countershaft and gear into the left
crankcase. Install the resin washer onto the
countershaft. Install the dowel pins and a new
gasket.
Tranmission case cover
Install the transmission case cover.
Install and tighten the transmission case cover
bolts.
Install the clutch/driven pulley.
Install the rear wheel.
Install the rear brake cable.
Gasket
Dowel pin
Movie S 125i
