10. FINAL REDUCTION
10-6
Install and tighten the oil check bolt.
Torque : 1.0~1.5 kgf-m
After installation, fill the transmission case with
the specified oil.
Place the motorcycle on its main stand on
level ground.
Check the oil sealing washer for wear
or damage.
Specified gear oil : SAE90#
Oil Capacity At disassembly
At change
:
140 cc
120 cc
Drain bolt
Filler hole
Fill the transmission with the recommend fluid to
the capacity listed below.
Movie S 125i
