5. Fi INJECTION SYSTEM MOVIE S 125i
5-19
Measure the resistance for the engine
temperature sensor’s wires
Standard: 8.24~14.4KΩ
Torque: 60~90 kg-cm
INJECTOR
Inspection
Measure the resistance of the Injector
Standard (20°C/68°F ): 10.6~15.9Ω
ECU Bolt
Injector
Replace a new O-ring and lubricate with
engine oil before installation.
The cleaner must be used for fuel injector
special only.
To Next Page
